Netgate 1541 TNSR Secure Router
Popis
TNSR Secure Router s Intel “Xeon-DE” D-1541, FCBGA 1667 supported SoC AES/NI and Intel QuickAssist
• CPU Intel “Xeon-DE” D-1541, FCBGA 1667 supported SoC AES/NI and Intel QuickAssist
• CPU Cores: 8 Cores, 45W
• Networking: 2x 1GB LAN via Intel® i350-AM2 1 Gigabit Ethernet, 2x 10GB LAN via SoC 10GBase-T,
• Storage: 150GB or 2x 150GB SSD RAID1
• Memory: 16 GB DDR4 UDIMM
• USB Ports: 2x USB 3.0 ports
• LED: Power LED
• Cooling: 200W Low-noise PS with PFC: Active CPU fan, 40mm chassis fan
• Power: 1x SATA DOM power connector 100-240V, 50-60Hz, 2.6 Amp MAX German Powercord IEC320-C13
• Environmental: 10°C to 35°C Operating Temp8% to 90% Operating Relative Humidity (non-condensing)
• Power Consumption: TBD (idle)
• Certifications: FCC, CE, RoHS, UL
Produktový manual.
| Základní deska | Netgate 1541 |
| CPU | Intel “Xeon-DE” D-1541, FCBGA 1667 supported SoC AES/NI and Intel QuickAssist |
| RAM | 16 GB DDR4 UDIMM |
| GLAN | 4 |
| SPF | SPF nebo SPF+ |
| USB | 2x USB 3.0 ports |
| Kryt | Standard 19″ 1U rack mount |
| Napájecí zdroj | 1x SATA DOM power connector 100-240V, 50-60Hz, 2.6 Amp MAX |
| HDD | 150GB nebo 2x 150GB SSD RAID1 |
| Console Port Cable | USB 2.0 A na Micro 5 pin 1.8mm |
| OS | TNSR |
| Výrobce | Netgate |
